Double-Sided Tape · PET
Double Sided PET Tape ZDP8160B
ZDP8160B is a solid black double coated adhesive tape with flexible thin filmic PET backing and acrylic adhesive. It has very good light blocking feature and very suitable to be used in fastening application where light blocking function required.
Product specifications
| Property | Value | Condition / test method |
|---|---|---|
| Backing | PET | |
| Adhesive | Acrylic | |
| Tape Colour | Black | |
| Tape Thickness (µm) | 160 | |
| 180° Peel Adhesion to Steel (N/25mm) | ≥ 15 | Test method: ASTM D3330 |
| Holding Power (Hr) | ≥ 24 | at 25°C, 1kg, 25mmx25mm · Test method: ASTM D3654 |
| Temperature Resistance (°C) | 80 |
- Backing
- PET
- Adhesive
- Acrylic
- Tape Colour
- Black
- Tape Thickness (µm)
- 160
- 180° Peel Adhesion to Steel (N/25mm)
- ≥ 15
- Test method: ASTM D3330
- Holding Power (Hr)
- ≥ 24
- at 25°C, 1kg, 25mmx25mm · Test method: ASTM D3654
- Temperature Resistance (°C)
- 80
Features
- Excellent light blocking
- High adhesion and temperature resistance
- High shear resistance
- Provide high bonding effect relative to low thickness of adhesive with good repulsion resistance
- Dimensional stable release liner provides good die cut ability
Product applications
- Suitable for application whereby light blocking function required
- Suitable for application that requires strong bonding such as window lens fixing, O ring in the hand-held device and also electronics components which bonding area are limited such as headphones, MP4, accessories like speakers and receiver
- Suitable for mounting of plastic and foam parts for electronic and electrical home appliances, medical instruments and automotive interior parts
