Single-Sided Tape · Polyimide
Single Sided Polyimide Tape ZSI9035
ZSI9035 is a high temperature resistant single-sided pressure-sensitive tape with polyimide film as the base material and coated with silicone adhesive.
Product specifications
| Property | Value | Condition / test method |
|---|---|---|
| Backing | Polyimide | |
| Adhesive | Silicone | |
| Tape Colour | Amber | |
| Tape Thickness (mm) | 0.035 | |
| Breakdown Voltage (kV) | 4.0 | Test method: PSTC-51 |
| Elongation at break (%) | 50 | Test method: PSTC-31 |
| Tensile Strength (N/25mm) | 115 | Test method: PSTC-31 |
| Peel Adhesion on Steel (N/25mm) | 3.5 | Test method: PSTC-101 |
| Temperature Resistance (°C) | 250 |
- Backing
- Polyimide
- Adhesive
- Silicone
- Tape Colour
- Amber
- Tape Thickness (mm)
- 0.035
- Breakdown Voltage (kV)
- 4.0
- Test method: PSTC-51
- Elongation at break (%)
- 50
- Test method: PSTC-31
- Tensile Strength (N/25mm)
- 115
- Test method: PSTC-31
- Peel Adhesion on Steel (N/25mm)
- 3.5
- Test method: PSTC-101
- Temperature Resistance (°C)
- 250
Features
- High temperature resistance
- Good insulation
- Dimensionally stable
Product applications
- Suitable for gold masking for PCB
